    USB Interface IP67 84 Keys ABS Plastic PC Keyboard

    Ask Lasest Price
    Brand Name : guangzhi
    Model Number : GZ-C004043-K819
    Certification : CE、FCC、RoHS
    Price : To be quoted
    Payment Terms : T/T, Paypal
    Supply Ability : 100000pcs
    Delivery Time : 1-20 work days
    • Product Details
    • Company Profile

    USB Interface IP67 84 Keys ABS Plastic PC Keyboard

    Desktop plastic PC keyboard for notebook with USB interface of mouse touch screen

    Prod uct Name: Pin Code Keypad

    Product P/N:GZ-C004043-K819

    Product Size: 260*210*14.5mm

    Application scope
    Bank self-service deposit and withdrawal service equipment, telecommunications, tax, self-service billing inquiry machine, self-service terminal, public information inquiry equipment, automatic monitoring, security equipment, industrial PC numerical control platform, medical testing equipment, self-service payment machine
    Mechanical parameters
    Key: 84 keys.
    Key design: scissor foot key structure, black key cap, blue and white two-color screen printing.
    Key stroke: 1.5mm
    Key life: ≥ 5 million times
    Shell: ABS raw material
    Weight: 0.65kg
    Electrical parameters
    Working voltage: DC + 4.5 ~ + 5.5V
    Working current: ≤ 30mA
    Expected service life: > 2 years
    Interface type: PS / 2 power line with magnetic ring, 1.8m long
    Operating system: DOS / Windows98 / me / 2000 / XP / win7
    Environmental adaptability:
    Working temperature: - 10 ~ 50 ℃
    Storage temperature: - 20 ~ 60 ℃


    Key FormABS Plastic button,Internal single-silica crater form
    Key Numbers84 keys
    Key Trip2.5mm
    Key life≥5 million times
    ColourBlack
    Touch pad size65*49mm
    InterfaceUSBPower cord length:1.5±0.05m(OD=4.5mm Black line blackhead)
    PS/2Power cord length:1.8±0.05m(OD=4.5mm Double line)
    Packaging methodNeutral packing 435*180*40mm
    Box size

    260*210*14.5mm

    Operating Voltage4.5--5.5V DC
    Working current≤30mA (IC<3mAh,LED< 22mAh,The remaining power consumption is less than 3mA)
    Operating temperature0-55℃
    Storage temperature-10—60℃Absolute input voltage: -0.3-+6V
    Absolute supply voltage-0.5V—6.5V
    Working WayConnect the interface to a terminal instrument such as a computer,When typing the corresponding key,The top three indicators will light up/off accordingly,Pressing another button will mark the corresponding character in the computer.When you tap/slide the touch pad with your finger, the cursor on the display will move accordingly;Click the two keys at the bottom of the touch pad,The left and right key reactions of the mouse are made in the display.
    Packing informationPacking 10/box, net weight:7KG, Gross weight:8KG

    Compatible with: windowns98 / 95 / NT / me / 2000 / XP / Vista / 7.0 / 8.0
