Pc Pin Code Keypad Oem Brand For Public Information Inquiry Equipment

    Buy cheap Pc Pin Code Keypad Oem Brand For Public Information Inquiry Equipment from wholesalers

    Buy cheap Pc Pin Code Keypad Oem Brand For Public Information Inquiry Equipment from wholesalers
    • Buy cheap Pc Pin Code Keypad Oem Brand For Public Information Inquiry Equipment from wholesalers

    Pc Pin Code Keypad Oem Brand For Public Information Inquiry Equipment

    Ask Lasest Price
    Brand Name : guangzhi
    Model Number : GZ-Z012043
    Certification : CE、FCC、RoHS
    Price : To be quoted
    Payment Terms : T/T, Paypal
    Supply Ability : 100000pcs
    Delivery Time : 1-20 work days
    • Product Details
    • Company Profile

    Pc Pin Code Keypad Oem Brand For Public Information Inquiry Equipment

    Wholesale Best New Custom Wired USB PC Computer Keyboards OEM Brand Cheap Laptop Keyboard

    Prod uct Name: Pin Code Keypad

    Product P/N:GZ-Z012043

    Product Size: 400*135.5*13mm

    Application scope
    Bank self-service deposit and withdrawal service equipment, telecommunications, tax, self-service billing inquiry machine, self-service terminal, public information inquiry equipment, automatic monitoring, security equipment, industrial PC numerical control platform, medical testing equipment, self-service payment machine
    Mechanical parameters
    Key: 86 keys.
    Key design: scissor foot key structure, black key cap, blue and white two-color screen printing.
    Key stroke: 1.5mm
    Key life: ≥ 5 million times
    Shell: ABS raw material
    Weight: 0.65kg
    Size: 400 * 135.5 * 13mm
    Electrical parameters
    Working voltage: DC + 4.5 ~ + 5.5V
    Working current: ≤ 30mA
    Expected service life: > 2 years
    Interface type: PS / 2 power line with magnetic ring, 1.8m long
    Operating system: DOS / Windows98 / me / 2000 / XP / win7
    Environmental adaptability:
    Working temperature: - 10 ~ 50 ℃
    Storage temperature: - 20 ~ 60 ℃


    Key FormABS Plastic button,Internal single-silica crater form
    Key Numbers87 keys
    Key Trip2.5mm
    Key life≥5 million times
    ColourBlack
    Touch pad size65*49mm
    InterfaceUSBPower cord length:1.5±0.05m(OD=4.5mm Black line blackhead)
    PS/2Power cord length:1.8±0.05m(OD=4.5mm Double line)
    Packaging methodNeutral packing 435*180*40mm
    Box size

    400*135.5*13mm

    Operating Voltage4.5--5.5V DC
    Working current≤30mA (IC<3mAh,LED< 22mAh,The remaining power consumption is less than 3mA)
    Operating temperature0-55℃
    Storage temperature-10—60℃Absolute input voltage: -0.3-+6V
    Absolute supply voltage-0.5V—6.5V
    Working WayConnect the interface to a terminal instrument such as a computer,When typing the corresponding key,The top three indicators will light up/off accordingly,Pressing another button will mark the corresponding character in the computer.When you tap/slide the touch pad with your finger, the cursor on the display will move accordingly;Click the two keys at the bottom of the touch pad,The left and right key reactions of the mouse are made in the display.
    Packing informationPacking 10/box, net weight:7KG, Gross weight:8KG

    Compatible with: windowns98 / 95 / NT / me / 2000 / XP / Vista / 7.0 / 8.0
